2MP 1080P Hybrid AHD TVI CVI CVBS Panoramic 360 HD Video Surveillance Camera(MVT-AH60P)

2MP 1080P Hybrid AHD TVI CVI CVBS Panoramic 360 HD Video Surveillance Camera(MVT-AH60P)

  • Model Number: MVT-AH60P
  • Type: Panorama Camera
  • Style: Dome camera
  • Camera Sensor: CMOS
  • Resolution: 2MP/1080P
  • Lens: 1.7mm (M12) Lens
  • IR leds: 3 pcs 3rd generation LED Array
  • IR Distance: 15m
  • 4 in 1: AHD, TVI, CVI,CVBS

2MP 1080P Hybrid AHD TVI CVI CVBS Panoramic 360 HD Video Surveillance Camera(MVT-AH60P)


Main Features:

• 2MP 1081P full real-time

•Follow AHD, TVI, CVI, CVBS video standard
•3 pcs 3rd generation LED Array,15m IR Distance, Vandalproof Camera
•With 5MP 1.7mm (M12) Lens

• support transmission distance above 300M under general 75- 3 coaxial cable
• High-speed, long-distance, real-time transmission
• support OSD menu
• with ICR switching , to achieve Day and Night monitoring

•Used genuinely imported 3rd generation IR LEDs and megapixel high definition lens, these cameras have been featured as great performance in color restoration,image definition and night viewing.



Application Places
Apply to the financial, supermarket, telecommunications, government, schools, airports, factories, hotels, museums and other places of requirement of high-definition.

 Model MVT-AH60P
 Sensor  1/2.9” CMOS(IMX323+8902H), 2.0MP/1080P
 SIGNAL  PAL / NTSC
 Video Output AHD/TVI/CVI/CVBS 4 IN 1
Effective Pixels 1920(H)*1080(V)
 Min. Illumination 0.01Lux F1.2
 Shutter 4/25s~1/45,000s
 Synchronization Internal
 Video Output Interface 1CH BNC
BLC/DWDR optional
OSD optional
 AWB Automatic / manual / day / night
 Day/Night Auto(ICR) / Color / B/W
 Transmission Distance  Over 300m via coaxial cable
 Power Supply  DC 12V±10%
 Working Environment  -30°C~+60°C/Less than 95%RH(no condensation)
 Power Consumption 4W MAX

2MP 1080P Hybrid AHD TVI CVI CVBS Panoramic 360 HD Video Surveillance Camera(MVT-AH60P)
2MP 1080P Hybrid AHD TVI CVI CVBS Panoramic 360 HD Video Surveillance Camera(MVT-AH60P)

2MP 1080P Hybrid AHD TVI CVI CVBS Panoramic 360 HD Video Surveillance Camera(MVT-AH60P)


2MP 1080P Hybrid AHD TVI CVI CVBS Panoramic 360 HD Video Surveillance Camera(MVT-AH60P)
