5MP 3MP 2MP 1MP HI3535 Chipset Factory Price 32CH NVR Support 2pcs HDD MVT-N6432
- Model:MVT-N6432
- Chipset:HI3535
- Channel：32CH; Compression：H.264
- Resolution:5MP 3MP 2MP 1MP
- Support:HDMI,P2P Remote view
- SATA: 2pcs; USB Port: high speed 2 pcs
- languages:28 kinds
5MP 3MP 2MP 1MP HI3535 Chipset Factory Price 32CH NVR Support 2pcs HDD MVT-N6432
2.NVR:32CH 960P@25fps recording, 8CH 960P playback；
3.NVR:6CH 1080P@25fps recording, 6CH 1080P playback；
4.NVR:16CH 720P@25fps recording, 16CH 720P playback；
5.NVR:25CH 3.0MP@25fps recording, 4CH 3.0MP playback；
6.NVR:16CH 5.0MP@25fps recording,2CH 5.0MP playback；
| Model | MVT-N6432 | |
| Compression | H.264 Standard compression | |
| Operation | Embedded Linux | |
| Image coding-control | Image edit adjustable,both changable and fix stream optional | |
| Dual stream | Can be set up in each channel | |
| Monitor image quality | 5mp, 3mp, 2mp, 1mp | |
| Image dynamic detection | Multiple detection areas in each channel | |
| Video framerate | 25fps | |
| Image playback quality | Optional | |
| Video mode | Support manual, automatic, dynamic monitoring, alarm trigger video mode | |
| Backup mode | U disk, USB portable disk, USB burn, Network storage and backup | |
| Operate mode | Mouse, remote controller, front panel | |
| login locally | without password | |
| Save recording | local hard disk and network | |
| External interface | Video input | 32CH |
| Audio input | no | |
| Network interface | 10M/100M base-T Ethernet (RJ-45) | |
| USB connect port | 2*USB 2.0 | |
| Internal HDD | 2 SATA HDD port | |
| Maximum capacity | Maximum 4TB each SATA | |
| Cell phone monitoring: Support Window Mobile, iPhone,iPad, Android | ||
| Power: 12V/3A | ||
| DVR size | 340(L)*265(W)*70(H)mm | |
| Weight | <3.5kg(without HDD) | |
1)Does the nvr come with hard disk?
The nvrs don’t come with hard disk. If you need buy hard disk from us,we could install hard disk into nvr.
2)How to increase recording time?
a.Install more hard disks
b.set the dvr to motion detection record
c.reduce the recording resolution and frame rate
3)Does the nvr support P2P?
Yes,the dvr come with cloud id,support P2P remote view on mobile phone and computer.
4)what's the mobile phone view app of the nvr?
The mobile phone app is "XVR"
The nvrs don’t come with hard disk. If you need buy hard disk from us,we could install hard disk into nvr.
2)How to increase recording time?
a.Install more hard disks
b.set the dvr to motion detection record
c.reduce the recording resolution and frame rate
3)Does the nvr support P2P?
Yes,the dvr come with cloud id,support P2P remote view on mobile phone and computer.
4)what's the mobile phone view app of the nvr?
The mobile phone app is "XVR"
5)How to correctly turn off NVR?
First, turn off in DVR menu, and then cut off the power. Do not cut off the power directly, DVR may be damaged due to misuse.
6)How to recover NVR password?
We could provide application "GenSuperPassword" ,you can use the application to recover password.
6)How to recover NVR password?
We could provide application "GenSuperPassword" ,you can use the application to recover password.
7)Does your NVR support ONVIF IP camera ?
We suggest you make a test sample,NVR support ONVIF,but IP camera and NVR from different factory are not compatible.
We suggest you make a test sample,NVR support ONVIF,but IP camera and NVR from different factory are not compatible.
8)Does NVR support POE?
At present,our NVR don't support POE.
At present,our NVR don't support POE.
