Low Cost AHD Bank Security indoor use with LED array

Low Cost AHD Bank Security indoor use with LED array

  • Model Number: MVT-AH43A/N
  • Camera Sensor: CMOS
  • Definition:720P/1024P optional
  • Lens: 6mm,fixed
  • IR leds: LED array
  • IR Distance: 30m
  • Bracket: 3-Axis bracket with cable built in

Main Features:

• 1.0M/1.3M/2.0M pixel full real time optional,Highest resolution 1080P
•follow HD and CVBS video standard
•6mm(M12) fixed Lens
•Water Resistant Rate:IP66

• support transmission distance above 500M under general 75- 3 coaxial cable without loss

• High-speed, long-distance, real-time transmission
• support OSD menu
• with ICR switching , to achieve Day and Night monitoring

•Used genuinely imported 3rd generation IR LEDs and megapixel high definition lens, these cameras have been featured as great performance in color restoration,image definition and night viewing.





Application Places:
Apply to the financial, supermarket, telecommunications, government, schools, airports, factories, hotels, museums and other places of requirement of high-definition.




 Model

MVT-AH43A

MVT-AH43N

 Sensor

 1/4" CMOS pixelplus

1.0M/ 720P OV9712

 1/4" CMOS pixelplus

1.0M/ 720P AR0141

 SIGNAL

 PAL / NTCS

 Video Output

 HD-AHD/CVBS

Effective Pixels

 1280(H)*720(V)

 1280(H)*720(V)

 Min. Illumination

0.01Lux F1.2

 Shutter

4/25s~1/45,000s

 Synchronization

 Internal

 Video Output

1-channel BNC HDAHD/CVBS high definition video output

BLC

optional

 OSD

optional

 AWB

Automatic / manual / day / night

 Day/Night

Auto(ICR) / Color / B/W

 Transmission Distance

 Over 500m via 75-3 coaxial cable

 Power Supply

 DC 12V±10%

 Working Environment

 30°C~+60°C/Less than 95%RH(no condensation)

 Power Consumption

4W MAX
