Vandal-proof Aptina CMOS 3MP Waterproof Vari-focal Lens Dome AHD Camera(MVT-AH23F)

  • Model Number: MVT-AH23F
  • Type: Dome AHD Camera
  • Camera Sensor:1/3"CMOS
  • Resolution:3MP
  • Lens: 2.8-12mm varifocal lens
  • IR LEDs: 36pcs
  • IR Distance: 30m
  • with IR Cut
  • Waterproof available
  • Certificate:CE,ROHS,FCC
  • Warranty:2 years
Vandal-proof Aptina CMOS 3MP Waterproof Vari-focal Lens Dome AHD Camera(MVT-AH23F)

1-Adopt 1/3" AR0330 CMOS and high performance NVP2470H DSP,reach to 3MP(2048*1536) resolution
2-2.8-12mm(M12) vari-focal Lens
3-Waterproof available(inform us you need waterproof feature when place order)
4-75- 3 general support under the coaxial cable transmission without loss
5-High-speed, long-distance, real-time transmission
6-Support OSD
7-with IR Cut for day&night mode switching


Applications:

Finance, supermarkets, telecommunications, government, schools, airports, factories, hotels, museums and other places to apply the high-resolution requirements.


Model MVT-AH23F
 Sensor 1/3"CMOS  (AR0330+NVP2470H ) 3.0MP
 SIGNAL  PAL / NTCS
 Video Output AHD/CVBS
Lens 2.8-12mm(M12) vari-focal Lens
IR Distance 36pcs×Φ5 IR leds,30m IR Distance
 Min. Illumination 0.01Lux F1.2
 Shutter 4/25s~1/45,000s
 Synchronization  Internal
BLC optional
 OSD optional
 AWB Automatic / manual / day / night
 Day/Night with IR Cut, Auto(ICR) / Color / B/W
 Transmission  Over 500m via 75-3 coaxial cable
 Distance
 Power Supply  DC 12V±10%
 Working   30°C~+60°C/Less than 95%RH(no condensation)
Environment
Waterproof  available
Warranty  2 years
 Power  4W MAX


Products Pictures:
Upgrade Waterproof Dome Metal Housing AHD Camera with 2.8-12mm Vari-focal Lens(MVT-AH23)

FAQs:
Q1:Whether the dome camera is waterproof?
Yes,this dome camera can be made with waterproof feature,but please inform us you need this feature when arranging the order.
Q2:Can I view the camera on mobile phone and computer?
After connect the camera to DVR,you can view the camera thru network view function of DVRs.
Q3:Does the 3MP AHD Camera can connect my 3MP AHD DVR?
Yes,AHD Camera is same as CVBS camera,it is compatible with all AHD DVR.
Q4:Do you have 3MP AHD DVR?
Still don't have,but we are following the 3MP AHD DVR technology,will coming soon.
Q5:Can I test sample before place mass order?
Sure,sample order is welcomed,MOQ is 1pc.

where to buy Chinese outside home security surveillance cameras


Package: MVTEAM Brand Box Or Netural Box Or Specified by customer.

where to buy Chinese outside home security surveillance cameras-MVTEAM
Shipping: Based on the your demands to choose the best shipping way.
