1）Built-in OSD menu, can change information and parameter of dome through menu, also can set and call presets,
   tour, scan, pattern, camera mode and display name etc.
2）Horizontal Speed（0.1°～220°/s）,  Vertical Speed（0.1°～180°/s）
3）Screen display position of pan/tilt, zoom, temp inside, direction lable, time and date.
4）128 presets (titles can be set); Tour is based on presets, speed & park time of presets can be set.
5）Pan 360° continuously, tilt 90° rotation, auto-flip, manual speed: 0.4°～320°/s.
6）4 pattern, and each record time is not less than 180s.
7）4 scan, support scan between left and right limite at an appointed speed.
8）Auto scan function, and at the same time, dome can still zoom, and run tilt
9）Park action function, can auto-call presets or start-up tour, pattern and scan after dome id for a period of time
10）Communication (support Rs485).
11）Built-in multi-protocols and fully compatible with PELCO-D、PELCO-P
12）IP66 all-day protection cover, built-in constant temperature device.
13）Built-in TVS4000V lightning-proof, surge-proof and wave-proof.

PTZ Specs
Manual speed	Pan（0.1°～300°/s）
	Tilt（0.1°～220°/s）
Preset speed	220°/s
Rotation	Pan continuously 360°, tilt 0～90° with auto-flip
Speed Proportion	As the length of focus, to auto-adjust the speed
Preset	128 preset, title can be edited
Auto-flip	Tilt down 90°, with auto-flip 180°
Scan	355°programmable, 4 scan
Decoder	Built-in
Video output	Female BNC
Romote controlling	RS485
Baud rate (RS485)	2400／4800／9600/19200 bps
ID range	1～254
Temperature	Outdoor -10℃～+60℃
Humidity	0～95%（non-condensation）
Protection grade	IP66,  lightning-proof, surge-proof, wave-proof, all-day defend cover
Power supply	AC 24V ±4V
Power consumption	Indoor 10W
Temperature	-10℃～+60℃
Gross weight	2.9kg
Cam Specs
CMOS	1/3" Sony CMOS Sensor
	1305(H) × 1049(V) Approx. 1.37M pixels
OPTICS	Optical x20, f = 4.7 mm ~ 84.6.0 mm
Angle	Appr. 55.2°(Wide) to 3.2°(Tele)
Scanning System	Progressive Scan
Min. Illumination	Color : 0.5 lux , BW : 0.1lux
S/N (Y signal)	52dB
White Balance	Auto
ICR	Manual/Auto
DNR	Auto / Off / Low / Middle / High
HLC	Off / On
Defog	Off / On
Max Gain	Auto
IRIS	Auto
FLIP	Vertical , Horizontal ,Vertical-Horizontal,OFF Selectable
